Feeding Equipment
Vibrating Feeder for Mining and Stone Crushing Plants
Vanore Mining supplies vibrating feeder equipment for quarry, aggregate, mining and mineral processing plants. The feeder delivers stone, ore and bulk materials into crushers or screening systems with stable, continuous flow.
Brand and Product Overview
Heavy-Duty Vibrating Feeder from Vanore Mining
Vanore vibrating feeder is engineered for feeding bulk stone, ore and mineral materials from a hopper into jaw crushers, impact crushers, cone crushers or screening equipment. The machine supports consistent material delivery; its hopper and discharge interfaces are matched to the receiving equipment.
The trough, vibration drive, springs and frame deliver a controlled material flow from the hopper to downstream equipment. Vanore Mining integrates vibrating feeders with crushing, screening and conveying systems for complete plant projects.
Manufacturing Display
Vibrating Feeder Equipment Gallery
Feeding Options
Vibrating Feeder Types and Configuration Options
Crusher Feeding
Feeds large stone or ore into primary crushing equipment with stable material flow.
Pre-Screening Feed
Can support material separation before crushing when matched with suitable grate design.
Aggregate Plant Feed
Works in quarry and aggregate plants before jaw crusher or impact crusher stages.
Mining Plant Feed
Supports ore feeding in mineral processing preparation lines.
Advantages
Vibrating Feeder Design Features
Stable Feeding
The vibration system supports continuous material flow into crushing equipment.
Heavy-Duty Trough
The trough and support structure are prepared for large stone and ore materials.
Feed Distribution
Consistent delivery helps maintain an even material bed at the crusher inlet and a steady flow through the crushing stage.
Wear Part Planning
Contact surfaces and wear areas can be planned according to material conditions.
Applications
Vibrating Feeder Applications
Jaw Crusher Feeding
Feeds primary crushing equipment in quarry and mining plants.
Stone Crushing Plant
Supports aggregate production before crushing and conveying stages.
Ore Processing
Feeds mineral materials before crushing and beneficiation preparation.
Sand and Gravel
Handles bulk materials in sand and gravel processing lines.
Mobile or Fixed Plants
Can be configured for mobile or stationary material handling systems.
Applicable Materials
Materials Suitable for Vibrating Feeding
Vibrating Feeder Technical Specifications
| Model | Feed trough length × width (mm) | Maximum feed size (mm) | Feeding capacity (t/h) | Motor power (kW) | Weight (t) | Overall dimensions (mm) |
|---|---|---|---|---|---|---|
| ZSW-380 × 96 | 3800 × 960 | 500 | 120-210 | 11 | 4.2 | 3850x1950x1630 |
| ZSW-420 × 110 | 4200 × 1100 | 650 | 180-400 | 15 | 4.8 | 4400x2050x1660 |
| ZSW-490 × 110 | 4900 × 1100 | 650 | 280-500 | 15-18.5 | 5.6 | 5200x2050x1700 |
| ZSW-490 × 130 | 4900 × 1300 | 750 | 300-550 | 22 | 6.7 | 5200x2350x1750 |
| ZSW-600 × 130 | 6000 × 1300 | 800 | 400-750 | 30 | 8.2 | 6160x2580x2293 |
| ZSW-600 × 150 | 6000 × 1500 | 900 | 500-900 | 37 | 10.3 | 6160 × 2919 x2293 |
Material flow and crusher matching
Trough length and width define the feeding surface. Vanore matches the hopper outlet, feeder discharge and receiving crusher to the material size and required feed rate.
Bulk density, grading, moisture and bed depth help define the feeding duty. The table lists feeder capacity and drive power; the complete crushing line is sized around the required products and downstream equipment.
Product Structure
Main Structure of Vanore Vibrating Feeder
Feeding Trough
Guides bulk materials toward the crusher or conveyor.
Vibration System
Provides feeding motion for stable material delivery.
Spring Support
Supports vibration and helps maintain operating stability.
Drive Motor
Transfers power for continuous feeding operation.
Support Frame
Holds the feeder body in working alignment.
Discharge End
Connects with crushing or conveying equipment.
Circuit Integration
Vibrating Feeder in a Complete Crushing Line
Vanore Mining designs feeding equipment as part of a complete crushing and screening line. The feeder can connect with hoppers, crushers, conveyors and screening equipment for continuous plant operation.
Related equipment: Jaw Crusher, Stone Crusher Plant and Mining Equipment Manufacturer.
Vibrating Feeder Equipment Scope and Process Connections
| Equipment group | Role and connection |
|---|---|
| Trough and wear surfaces | Receive the prepared bulk feed and carry it toward the discharge. Impact loading and abrasion influence the contact-surface arrangement. |
| Vibration drive and supports | Provide conveying motion and support the moving assembly. The structure must account for the selected equipment and its dynamic loading. |
| Hopper and discharge transfer | Define how material enters the feeder and reaches the crusher. Hopper geometry, drop height and discharge alignment are installation interfaces, not the trough dimensions alone. |
| Scalping and bypass | Where grizzly bars form part of the configuration, undersize can leave through a separate route while the retained material continues toward the crusher. |
Controlled feeding and separate material routes
Vanore integrates feeders with primary jaw crushers and suitable impact-crushing duties. The hopper and discharge arrangement help keep material moving consistently into the crushing stage.
A grizzly section separates undersize ahead of crushing, while a finished-product sizing screen sorts the crushed material into the required grades. The undersize route is arranged around the plant’s material and product requirements. Stationary lines and mobile crushing systems require their own support and transfer layouts.
Vibrating Feeder FAQ
How does the feeder fit into a crushing line?
The feeder delivers bulk stone or ore from the hopper to the primary crusher. Matching its discharge with the crusher inlet helps maintain a steady flow through the crushing stage.
What influences feeding capacity?
Bulk density, material grading, moisture, bed depth and hopper discharge affect the feed rate. Vanore uses these conditions together with the required throughput to match the feeding arrangement.
Which dimensions matter for the installation?
Trough length and width define the feeding surface. Hopper outlet size, discharge height, crusher inlet and support structure complete the installation layout.
How does a grizzly section handle undersize?
Undersize passes through the grizzly bars into a separate route, while the retained material continues to the crusher. This allows suitable fines to bypass the primary crushing stage.
Can a feeder work in a fixed or mobile crushing plant?
Yes. Feeders can be integrated into stationary or mobile crushing systems, with the supports, hopper and discharge connections matched to the plant layout.
Contact Vanore Mining
Discuss Your Feeding Arrangement
Share details of your material, bulk density, maximum feed size, required feed rate and receiving crusher. Vanore Mining can review the equipment arrangement and process connections.
